AutroSafe is our high-end fire detection system for large and complex buildings. Since its launch in 1999, it has proven its unique stability and reliability in more than 15,000 installations worldwide, from hotels to cruise ships to drilling platforms.

AutroSafe 4 provides advanced functionality for a wide range of applications. The system is designed to meet all requirements in the high-end segment of the onshore, maritime, and offshore market, and is certified according to the Marine Equipment Directive (MED) for Wheel marking, Construction Products Directive (CPD) for CE marking, both requiring EN 54-2 and 4 compliance and Factory Mutual (FM) approval according to NFPA 72.

Reliable communication is paramount to your safety. That’s why we have added AutroNet to the AutroSafe system, an innovative network solution safeguarding communication between panels. AutroNet ensures a redundant and high-speed network expanding the reach of the AutroSafe system even further. The system can be set up either in a star or ring network, depending on your needs.

A maximum of 64 system units (panels, controllers) can be connected to the AutroNet. The system has a great capacity, and the fact that all types of loop units can be connected to the same detection loop gives large flexibility. Uploading of configuration data or system software to the entire system can be done from one single point. The USB port is used for downloading data from a USB memory stick.

Maximum capacity

Panels per system:	64
Detection loop per panel:	6/12*
Loop units per loop:	127**
Loop units per PowerLoop:	15**
Units per AutroFieldBus:	31
Alarm units per loop:	40**
Loop units per panel, ref. EN 54:	512
Ethernet ports:	2
RS232/RS422/RS485:	1
AutroFieldBus interface:	1
USB port	1

* Max. 12 loops per panel/controller, where
6 can be placed inside the cabinet.
** Depending on cable choice
